Pyroplex® Pipe Collar 4 hr – O/D 55mm

 Pyroplex® Pipe Collar 4 Hour Fire Rated – 55mm Outside Diameter

The Pyroplex® Pipe Collar 4 Hour (55mm O/D) is a high-performance fire-stopping solution designed to reinstate the fire resistance of compartment walls and floors where plastic flammable pipes penetrate fire-rated elements. Ideal for soil, waste and drainage services, this collar provides up to 240 minutes of fire resistance, helping to maintain building integrity and compliance.

Engineered for ease of installation, the collar features a tab closing device that allows it to be quickly fixed around the pipe and either rotated or slid into position. Once exposed to fire, the advanced intumescent material expands rapidly, sealing the opening as the pipe softens or melts, preventing the spread of fire and smoke.

Key Features

• Provides up to 4 hours (240 minutes) of fire resistance

• Designed to seal flammable plastic pipes from 25mm to 400mm in diameter

• Suitable for soil, waste and drainage systems (above ground)

• Can be face fixed to walls or ceilings

• Tab closing mechanism for fast, secure installation

• Robust non-flaking intumescent material

• Intumescent compound is unaffected by water and is highly durable
• Stainless steel outer casing on 400 series collars

• Also available in other sizes upon request, please get in touch with [email protected]

Areas of Applications

• Concrete and masonry walls and floors
• Plasterboard partitions (PPC25 – PPC160 only)
• Service penetrations for:
  • Soil pipes
  • Waste pipes
  • Drainage pipes

Fire Performance & Certification

• Fire Rating: Tested to BS 476: Part 20 and BS EN 1366-3

• Fire Resistance: Up to 240 minutes

• Certifire Approved: Certificate Number: CF635
