CCE Appliqué One Size Surface Mounted Drop Down Seal

CCE Appliqué One Size Surface Mounted Drop Down Seal

Introducing a high-performance surface-mounted One Size drop-down seal that automatically closes the gap between the door and the floor when the door is shut. This product is ideal for retrofitting and is fire-rated for 60 minutes, making it suitable for installation on either side of timber doors. Unlike standard CCE Appliqué Surface Mounted Drop Down Seals, this One Size product can be cut down to 325 mm, providing greater flexibility for fitting specific door sets. It's a perfect addition to have on-site. One seal for all doors.

Key Features:

• Certifire approved.
• Includes a lock-side operation kit for activation from the lock side
• Comes in a silver anodised finish; other options can be ordered upon request
• Maximum drop: 14 mm
• Length: 1230mm
• Can be trimmed down to 325 mm

Areas of Application:

• For fire-rated doors, please refer to the Certifire certificate.
• Suitable for all non-fire-rated door types.

Fire Performance & Certification

• Fire Rating: Fire tested in accordance with Part 20&22: 1987, rated for 60 minutes
• Certifire Approved: CF5995
• Acoustic Rating: Complies with BS EN ISO 140-3:1995, achieving up to 28 dB Rw
• Smoke Rating: Complies with BS EN 1634-3:2004

Storage Guidance:

• Keep items in their original packaging
• Store boxes horizontally; do not bend or stack heavy weights on top
• Store in a dry place, protected from moisture, solvents, and direct sunlight

Product Specifications

• Length: 1230mm
• Fire Rated: 60 minutes fire-rated
• Finish: silver anodised finish
• Maximum drop: 14 mm
• Manufacturer: CCE
